Tube Diameter : 170Phi(Pyrex or Quartz)
Tube Length : 1.5m ~ 2m
Heater Zone : 6 ~ 7Zone
Max Temperature : ,800-
Loading Capa. : ,500g ~ 1kg
170phi
Purification Division
Pneumatic valve type
High vacuum pump : Diffusion pump
Rotary Pump : 10004/min
Ultimate Pressure : 3 X 10-6 Torr (D. Pump)
Ultimate Pressure : 8 X 10-5 Torr (Rotary Pump,
Fill with Liquid Nitrogen)
